BLDC MOTOR
| PERFORMANCE DATA |
| Model | Rated Voltage | Rated Power | Rated Torque | Rated Speed | Maximum Speed | Rated Current | Maximum Current | Insulation Class | Encoder Type | Environment | Weight | Duty |
| Units | VDC | W | N.m | rpm | rpm | A | A | Class | / | / | Kg | |
| 67BWA428D008B-01 | 48 | 400 | 5 | 300-750 | 1100 | 9 | 25 | F | Magnetic Encoders | 0-40 | 5.2 | 25% |
| OUTLINE MAP |
